DETAILS
| Model Number | MPO patchcord |
| Use | FO&FTTH |
| Warranty Time | 3 years |
| Network | Wireless Lan, 4g, 3G |
| Connector Type | MPO, MTP, LCMPO |
| MPO Connector (Core) | 12, 24, 16, 32 |
| LC Connector (2.0mm Loose Tube) | LC-HD, Uniboot, Duplex, Simplex |
| Fiber Type and Cable Color | Single-mode(G.657A1): Yellow |
| Cable Core | 4, 6, 8, 12, 24, 16, 32 Cores and Outer diameter=3.0mm |
| Cable Material | LSZH, Plenum(OFNP) or customized |
| Insertion Loss | MPO: Low Loss-IL≤0.35dB, Standard Loss-IL≤0.70dB |
| Return Loss | MPO: SM/RL≥55dB, MM/RL≥25dB |
